Description
The Mosmatic WDEI Swivel 40.465B – Box of 10 Units provides a durable, high-performance swivel solution for industrial hose reels and large-diameter fluid systems. Each swivel is made from premium stainless steel and designed for long-term reliability in high-pressure environments. Featuring a sliding bearing for smooth rotation and sealed with a standard O-ring NBR—with optional EPDM or FKM seals for chemical or high-temp applications—these swivels offer consistent performance under heavy use. With 1″ NPTF inlet and 1″ NPTM outlet, each unit supports 3000 psi, 30 RPM, and temperatures up to 250°F, making this 10-piece bulk pack ideal for OEMs, maintenance operations, and large-scale equipment installs.
Applications
-
Large-diameter hose reels
-
Commercial and industrial washdown systems
-
Chemical and food-grade processing equipment
-
Fluid transfer setups requiring corrosion resistance
-
OEM or maintenance installs for high-flow systems
Features
-
Box includes 10 stainless steel swivels
-
Thread IN: 1″ NPTF | Thread OUT: 1″ NPTM
-
Robust stainless steel construction for corrosion and pressure resistance
-
Sliding bearing ensures smooth, consistent rotation
-
Standard O-ring NBR seal with optional EPDM or FKM for chemical/media compatibility
-
Dimensions per unit: Overall Diameter – 2.35″ | Overall Length – 3.54″
-
Nominal Width (NW): 1″
-
Rated for up to 3000 psi and 250°F
-
Max operating speed: 30 RPM
Specs
Pressure: 3000 psi (20 MPa)
Temperature: 250°F
RPM: 30
Material Type: Stainless steel
Inner Part: Stainless steel
Seal: O-ring NBR (EPDM or FKM optional)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1″ NPTF
Thread Out: G2 1″ NPTM
Nominal Width (NW): 1″
Wrench Size (SW): 1.61
Length 1 (L1): 3.35
Length 2 (L2) (overall length): 3.54
Length 3 (L3): 1.89
Length 4 (L4): 2.36
Diameter (D1): 2.35
Box: 10 pcs
Weight: 37.7 oz
