Description
The Mosmatic WDEI Swivel 43.563B – Box of 25 Units offers a reliable, high-performance swivel solution for hose reels operating in demanding environments. Built from corrosion-resistant stainless steel, each swivel features a sliding bearing for smooth, controlled rotation. The standard O-ring NBR seal provides dependable sealing, with optional EPDM or FKM available for chemical resistance and high-temperature compatibility. Designed with 1/2″ NPTF inlet and 1/2″ NPTM outlet, these swivels handle up to 7300 psi, temperatures up to 250°F, and rotation speeds of up to 30 RPM€”ideal for OEMs, industrial maintenance, and high-volume service operations.
Applications
-
High-pressure hose reel systems
-
Industrial washdown and cleaning equipment
-
Fluid and chemical transfer systems
-
OEM hose reel and equipment assembly lines
Key Features
-
Box includes 25 stainless steel swivels
-
Thread IN: 1/2″ NPTF | Thread OUT: 1/2″ NPTM
-
Robust stainless steel body for long-term durability
-
Sliding bearing ensures stable, smooth rotation under pressure
-
Sealing options: O-ring NBR standard; EPDM or FKM optional for specialized media
-
Dimensions per unit: Overall Diameter – 1.57″ | Overall Length – 2.60″
-
Nominal Width (NW): 1/2″
-
Rated for 7300 psi pressure and 250°F maximum temperature
-
Operates at up to 30 RPM
Specs
Pressure: 7300 psi (50 MPa)
Temperature: 250°F
RPM: 30
Material Type: Stainless steel
Inner Part: Stainless steel
Seal: O-ring NBR (EPDM or FKM optional)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/2″ NPTF
Thread Out: G2 1/2″ NPTF
Nominal Width (NW): 1/2″
Wrench Size (SW): 0.87
Length 1 (L1): 1.97
Length 2 (L2) (overall length): 2.60
Length 3 (L3): 1.34
Length 4 (L4): 1.81
Diameter (D1): 1.57
Box: 25 pcs
Weight: 13.2 oz
