Description
The Mosmatic 50.133 QVS Quick Connection is a precision-engineered fitting built for high-pressure cleaners, hose reels, and quick coupling systems. Designed using brass, nickel-plated components, and durable plastic, this connection combines a compact, lightweight form with long-lasting performance under demanding conditions.
It features a G1 (QV) M22 x 1.5 F inlet thread, a nominal width of 1/4″, an overall diameter of 0.39″, and a length of 2.40″. Equipped with a standard NBR O-ring seal system (also available in EPDM or FKM options), it ensures excellent sealing and leak prevention. Rated for 3600 PSI, with a maximum RPM of 30 and temperature capacity up to 250°F, this quick connect delivers top-tier efficiency and durability for professional applications.
Applications
-
High-pressure washer systems
-
Hose reel and quick coupling configurations
-
Commercial and industrial pressure cleaning setups
-
Compact installations requiring durable, precise connections
Key Features
-
Made from brass, nickel-plated components, and plastic
-
Thread Inlet: G1 (QV), M22 x 1.5 F
-
Nominal Width: 1/4″
-
Overall Diameter: 0.39″ | Overall Length: 2.40″
-
Includes NBR O-ring seal system (EPDM/FKM optional)
-
Rated for 3600 PSI, 30 RPM, and 250°F max temperature
-
Compact, lightweight, and easy to install
-
Ideal for precise, secure, high-pressure connections
Specs
Pressure: 3600 psi (27.5 MPa) also avaliable as 7300 psi
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, Nickel plated, Plastic
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread IN: G1 (QV) M22x1.5 F
S1: 3/8″
Nominal Width (NW): 1/4″
Length 1 (L1) (overall length) : 2.40″
Diameter 1 (D1): 0.39″
Diameter 2 (D2): 0.42″
Diameter 3 (D3): 0.53″
Color: Blue
Weight: 2.10 oz
