Description
The Mosmatic 58.151 DYF Swivel is a high-performance rotary union for high-pressure cleaning systems. Featuring a 3/8″ NPTF inlet and a 1/4″ NPTM outlet, it offers a step-down connection ideal for transitioning between larger inlet hoses and smaller nozzles or spray lances.
Its nickel-plated brass body, combined with stainless steel internals and a carbide seal system, delivers smooth 360° rotation, reliability under high pressure, and long service life. Built for operating pressures up to 4000 psi, it includes weep holes to indicate seal wear or failure.
Applications
-
Pressure washers and mobile wash systems
-
Car wash underbody and boom systems
-
Industrial fluid transfer setups
-
Rotating nozzles with step-down connections
Features
-
Full 360° swivel with sealed bearing system
-
Carbide seal for durability and performance
-
Step-down: 3/8″ to 1/4″ threading
-
Maintenance-free design
-
Visual seal failure detection
-
Nickel-plated brass body for corrosion resistance
Specs
Product Type: High-pressure swivel – DYF
Part Number: 58.151
Pressure: 4000 psi
Temperature: 250°F
RPM: max. 2,000 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: Carbide
Throughput / Medium: pH 3–12 / filtered 10 microns / compressed air (290 psi)
Thread In (G1): 3/8″ NPTF
Thread Out (G2): 1/4″ NPTM
Nominal Width (NW): 1/4″
Wrench Size 1 (SW1): 0.87″
Wrench Size 2 (SW2): 0.67″
Diameter (D): 2.36″
Length 1 (L1): 1.45″
Length 2 (L2): 0.43″
Weight: 11.0 oz
