Description
The Mosmatic 55.063 DYCI Swivel is a high-flow, high-pressure swivel designed specifically for self-rotating applications such as surface cleaners and parts washers. Precision-crafted from stainless steel, this swivel offers superior corrosion resistance, durability, and performance under demanding conditions.
Engineered with a triple bearing system – including two radial ball bearings and one thrust bearing – it ensures stable rotation, even at high RPMs. It features a carbide seal system for long-lasting sealing and integrated weep holes to provide early warning of seal wear or failure. Built to handle pressures up to 5000 PSI, this swivel is ideal for professional-grade cleaning tools that require smooth rotation and high flow rates.
Applications
-
High-flow rotating surface cleaners
-
Pressure washer part washers
-
Self-rotating spray tools
-
Industrial and commercial cleaning systems
-
Equipment requiring reliable high-speed swivel performance
Key Features
-
Thread In: 1/4″ NPT Female
-
Thread Out: G3/8″ Male
-
Material: Full stainless steel construction
-
Triple Bearing System: 2 radial + 1 thrust bearing
-
Seal System: Carbide seal for extended life
-
Weep Holes: Built-in for early seal failure detection
-
High Pressure Capability: Up to 5000 PSI
-
Temperature Tolerance: Rated up to 250°F
-
High-Speed Operation: Supports up to 2000 RPM
-
Compact Size: Efficient design for easy installation in tight setups
Specs
Pressure: 5000 psi
Temperature: 250°F
RPM: max 2,000 rpm
Material Type: Stainless steel
Inner Part: Stainless steel
Seal: Carbide
Throughput/medium: ph 3–12 / filtered 10 microns, compressed air (290 psi)
Thread In: 1/4″ NPTF
Thread Out: G3/8″ M
Nominal Width (NW): 1/4″
Wrench Size (SW1): 0.87″
Wrench Size (SW2): 0.63″
Diameter (D1): 2.36″
Diameter (D2): 1.10″
Length 1 (L1): 2.28″
Length 2 (L2): 1.46″
Length 3 (L3): 0.47″
Length 4 (L4): 0.12″
Weight: 23.0 oz
