Mosmatic Dyci Swivel Joint 55.203: High-Performance Rotary Union with M21×1.5 Input and G3/8″ Output for Reliable Fluid Transfer

Description

The Mosmatic 55.203 DYCI Swivel is a high-quality, stainless steel swivel engineered for high-flow, high-pressure, self-rotating applications including surface cleaners and parts washers. It’s designed for continuous operation in demanding environments, delivering smooth, efficient rotation and long-lasting durability.

This model features a triple bearing system – with two radial ball bearings and one thrust bearing – to ensure stability and performance at high speeds and pressures. A carbide seal system provides reliable leak protection, and weep holes offer early detection of seal wear or failure. With a pressure rating of 5000 PSI, temperature tolerance up to 250°F, and speed capacity of 2000 RPM, this swivel is built for professional-grade results.

Applications

• Surface cleaners for commercial and industrial use

• Self-rotating high-pressure cleaning tools

• Parts washing equipment

• Rotary nozzles and spray bars

• Automated and robotic cleaning systems

Key Features

• Thread In: M21x1.5 Male

• Thread Out: G3/8″ Male

• Triple Bearing System: 2 radial + 1 thrust bearing

• Seal Type: High-durability carbide seal

• Built-In Weep Holes: For seal failure warning

• Stainless Steel Construction: Resists corrosion and wear

• Max Pressure: 5000 PSI

• Max RPM: 2000

• Max Temperature: 250°F

• Compact & Durable: Engineered for long-term, high-performance use

Specs

Pressure: 5000 psi
Temperature: 250°F
RPM: max 2,000 rpm
Material Type: Stainless steel
Inner Part: Stainless steel
Seal: Carbide
Throughput/medium: ph 3–12 / filtered 10 microns, compressed air (290 psi)
Thread In: M21x1.5M
Thread Out: G3/8″ M
Nominal Width (NW): 1/4″
Wrench Size (SW1): 0.75″
Wrench Size (SW2): 0.63″
Diameter (D1): 2.36″
Diameter (D2): 1.10″
Length 1 (L1): 2.28″
Length 2 (L2): 1.46″
Length 3 (L3): 0.47″
Length 4 (L4): 0.12″
Weight: 23.0 oz
