Mosmatic DGVI Rotary Swivel Union – Model 32769 with G1 and G2 3/8″ NPTF Threaded Ports

Description

The Mosmatic DGVI Swivel 32.769 is a premium stainless steel swivel connector designed for high-pressure hose reels, HP-Guns, and hydraulic systems. It features 3/8″ NPTF inlet and outlet ports with a single thrust ball bearing, enabling smooth live rotation under maximum pressure.

Crafted with robust stainless steel, this swivel ensures superior corrosion resistance, low maintenance, and long-lasting performance in demanding environments. Ideal for tangle-free hose operations in pressure washing and hydraulic applications.

Applications

• High-pressure hose reels

• Hydraulic systems

• HP-Guns and pressure washers

• Commercial cleaning equipment

• Tangle-free hose installations

Features

• Material: Full stainless steel construction

• Thread IN (G1): 3/8″ NPTF

• Thread OUT (G2): 3/8″ NPTF

• Overall Length: 2.87″

• Nominal Width (NW): 1/4″

• Wrench Size (SW): 0.94″

• Max Pressure: 7300 PSI

• Max RPM: 30

• Max Temperature: 250°F

• Bearing System: 1x thrust ball bearing

• Seal System: O-ring NBR (optional EPDM or FKM)

• Performance: Live rotation, zero maintenance, corrosion resistant

Specs

Pressure: 7300 psi (50 MPa)

Temperature: 250°F

RPM: max 30 rpm

Material Type: Stainless steel

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8″ NPTF

Thread Out: G2 3/8″ NPTF

Nominal Width (NW): 1/4″

Wrench Size 1 (SW1): 0.94″

Wrench Size 2 (SW2): 0.87″

Length 1 (L1) (overall length) : 2.87″

Weight: 7.1 oz
