Description
The Mosmatic DGG Swivel 33.553 (90 Degrees) is a high-performance brass swivel designed for high-pressure, self-rotating cleaning systems. With a compact 90° design, it is ideal for parts washers, tire cleaners, and industrial surface cleaners requiring precise fluid rotation and high durability.
This swivel includes a robust triple bearing system (2x radial and 1x thrust ball bearing) that ensures smooth operation under pressure. The O-ring NBR seal system provides reliable leak protection, with optional upgrades to EPDM or FKM for greater chemical compatibility. Its nickel-plated brass construction enhances corrosion resistance, while the bulkhead fitting makes installation seamless in various cleaning equipment.
Applications
-
High-pressure cleaning systems
-
Self-rotating nozzles
-
Parts washers and degreasers
-
Tire and underbody cleaning equipment
-
Industrial surface cleaning machines
Key Features
-
Design: 90° angled swivel
-
Material: Brass, nickel plated
-
Seal Type: O-ring NBR (optional EPDM or FKM)
-
Bearing System: Triple (2x radial, 1x thrust)
-
Thread IN (G1): M22x1.5M
-
Thread OUT (G2): G3/8″ M
-
Overall Diameter: 1.34″
-
Overall Length: 2.76″
-
Nominal Width (NW): 1/4″
-
Wrench Size (SW): 0.87″
-
Max Pressure: 4000 PSI
-
Max RPM: 1000
-
Max Temperature:
-
90°F at 1000 RPM
-
250°F at 30 RPM
-
-
Mounting Type: Bulkhead
-
Maintenance: Maintenance-free
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 90°F at 1000 RPM, 250°F at 30 RPM
RPM: max 1,000 rpm
Material Type: Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 M22X1.5M
Thread Out: G2 G3/8″M
Nominal Width (NW): 1/4″
Wrench Size 1 (SW1): 0.87″
Wrench Size 2 (SW2): 0.75″
Wrench Size 3 (SW3): 1.34″
Diameter (D) (overall diameter): 1.34″
Length 1 (L1) (overall length) : 2.76″
Length 2 (L2): 0.47″
Weight: 11.7 oz
