Mosmatic 51.354 High-Pressure Fitting – M18×1.5 Male (12-L) to 3/8″ NPTF Female

Description

• The Mosmatic 51.354 VER Fitting is a high-pressure stainless steel adapter designed for hybrid systems that combine metric profile ring connections with NPTF threads. With a M18x1.5 male thread and 12-L profile ring sealing surface on one end and a 3/8″ NPTF female thread on the other, this fitting ensures safe, leak-proof performance up to 7300 PSI.

  The profile ring face (12-L) allows for precise O-ring sealing against flat-face mating surfaces in metric hydraulic setups, while the NPTF (National Pipe Taper Fuel) thread provides a secure dry-seal connection to standard U.S. components.

  Applications:

  • Hybrid hydraulic and high-pressure cleaning systems

  • European metric profile-ring to NPT transitions

  • Pressure washers and car wash systems

  • Industrial fluid handling systems

  Features:

  • Max pressure: 7300 PSI

  • Threading: M18x1.5M with 12-L profile ring x 3/8″ NPTF

  • Stainless steel construction for maximum durability

  • Precision-machined for leak-free performance

  • Combines profile-ring sealing and tapered thread sealing

  • Manufactured in Switzerland by Mosmatic

Specs:

• Body Material Type: Stainless Steel

• Pressure: 7300 PSI

• Threading In: Male M18x1.5 (12-L Profile Ring)

• Threading Out: Female 3/8″ NPTF
